The Dahua PHGOA4.81 Outdoor Fixed SMD Module combines IP65 weatherproofing with 4,500-5,000 nits brightness in an ultra-light modular cabinet, ideal for shopping mall facades and corporate building exteriors.

Engineered for outdoor advertising and architectural display applications, the Dahua PHGOA4.81-FC Outdoor Fixed SMD Module uses a modular 1×1 meter cabinet design that weighs just 24kg with a slim 96mm thickness, making installation and transport significantly more manageable than conventional outdoor cabinets. The 4.81mm pixel pitch produces 4,500-5,000 nits of brightness, ensuring clear visibility under Pakistan’s intense daytime sunlight across Lahore, Karachi, and Islamabad installations. Front and rear IP65 protection shields the display from dust, rain, and humidity, while organized internal wiring improves long-term system stability and reduces maintenance complexity. The fanless passive cooling design ensures silent operation even during sustained outdoor use. A standout feature is the module’s support for 90-degree seamless splicing, enabling creative architectural installations and three-dimensional visual effects on building corners and curved facades. Front and rear maintenance access via a quick-lock mechanism allows technicians to service individual panels or replace power supplies efficiently without dismantling the surrounding display.

Key Features

• Ultra-light modular 1×1m cabinet — only 24kg and 96mm thick
• 4,500-5,000 nits brightness ensures visibility under direct sunlight
• IP65 protection on both front and rear for complete weatherproofing
• 90° seamless splicing enables creative corner and 3D architectural displays
• Fanless passive cooling for silent, reliable outdoor operation
• Quick-lock front and rear maintenance for fast on-site servicing
• Organized internal wiring improves long-term system stability
• 100,000-hour service life rated for continuous outdoor deployment

Technical Specifications
